The remote data acquisition IO module introduced by Wutongbolian is an IoT device designed for remote communication and data collection.

 It supports LORA wireless transmission, 4G data uploading to the cloud, multi-channel IO data collection, Modbus RTU protocol, and wireless 485 transparent transmission. This module enables data collection and Modbus protocol communication from PLCs such as Siemens, Mitsubishi, Omron, Schneider, Delta, and Inovance. It is suitable for industries including mining, oil wells, water conservancy monitoring, smart agriculture, intelligent transportation, smart factories, and industrial control.

Application Scenarios

1. By deploying sensors and monitoring equipment within rural sewage treatment stations, data such as water quality parameters, temperature, and pressure can be collected.

    This enables real-time monitoring and visual analysis of sewage treatment equipment. Furthermore, data analysis can be utilized to optimize the operational parameters and treatment efficiency of sewage treatment equipment, enhancing management levels.

2. Through PLC data collection from equipment within sewage treatment plants, process configurations such as equipment runtime, pump switches, and motor start/stop statuses can be monitored.

    This facilitates intelligent alarms for equipment status and operational parameters, and leverages platform maintenance functions for effective cost reduction and improved maintenance efficiency.

3. Fire control PLC cabinets and sensors in pump station rooms can be integrated into the system, enabling online monitoring and over-limit alarms for data such as water immersion, smoke, gas concentration, temperature, and humidity.

    Notifications can be sent via WeChat, SMS, email, or audible/visual alarms, allowing for timely remote control of fire control equipment like sprinklers and ventilation systems to prevent accidents or mitigate their impact.

IO Module Features

1. Flexible Local Networking: LORA point-to-point and point-to-multipoint transmission, suitable for medium to short-distance wireless transmission.

2. Wireless Data Transparent Transmission: Supports bidirectional data transparent transmission via serial ports and LORA, enabling wireless serial port functionality.

3. Multiple Frequency Bands Available: Supports both 433MHZ and 915MHZ wireless frequency bands domestically and internationally, with adjustable channels.

4. Rich Collection and Control Capabilities: Supports AI, DI, DO data collection and control functions, as well as Modbus read and write operations.
